Operating system

Electrical PLC

Output of vibration conveyor

20T/h

Maximum bearing capacity of track roller

1000kg

Separation zone wind speed

5～6m/s

Track end disc diameter

1200mm

Lifting amount of elevator

40t/h

Track end disk speed

3.5r/min

Lower screw conveyor throughput

40t/h

Track drive power

7.5 kw

Required compressed air pressure

0.5～0.6mpa

Track end disk spacing

1500mm

Ventilation is required

7500m³/h ～800m³/h

Shot blasting quantity

250kg/min*2

Total power

61kw
