Operating system

Electrical PLC

Number of carts

2 sets

Job cleaning time

5min/ hook

Load capacity of trolley

3t

The workpiece passes the maximum external dimension

3300*1500*1500mm

Trolley speed

12.5m/min

Number of shot blasting devices

12 sets

Projectile specification

(Cast steel shot) Ф0.8~1.2 mm

Shot blasting quantity

280 kg/min/ unit

Total power

390kw

Electric hoist lifting weight

1T/Taiwan

Ventilation is required

50000 ㎡/h

Electric hoist walking speed

0.5~2m/min

Machine dimensions

7350*5120*8350mm
